Angular contact ball bushings have inner and outer rings displaced along the bushing axis. This design accommodates combined loads, including radial and axial loads.
As the contact angle increases, the axial load-carrying capacity of angular contact ball bushings also increases. This angle determines how the combined load transfers from one ring to another, relative to a line perpendicular to the bushing axis.
